VDL-HS1500 Portable Power Station,

 VDL HS1500

1500W/331560mAh

Brand Name

VDL

Output Interface

Double USB,DC,USB-Type C

Input Interface

Special Interface

Battery Type

Lithium Battery

Shell Material

Plastic

Features

Built in Cables,Digital display,Charger & Battery in 1,With LED Lamp,With plug

Origin

Mainland China

Type

Outdoor High Capacity Power Supply

Certification

RoHS,CE,UL,FCC

Support Quick Charge Technology

Two-way Quick Charge

Model

HS1500

US AC Input:

Version 1: 100-120V,50/60Hz Max 700W

EU AC Input:

Version 2: 220-240V,50/60Hz Max 1000W

Input

DC5521: 12-30V Max 7A (Max 200W),XT60: 12-30V Max 10A (Max 300W)

6*AC output:

Rated Power: 1500W JP/US/AU

4*AC output:

Peak Power: 2000W UK/EU/UN

2*USB-C Output

PD100W (5V/9V/12V/15V/3A, 20V/5A)

4*USB-A Output

(QC3.0) Max 18W (5V/3A,9V/2A,12V/1.5A)

1*Car Socket Output

Max 108.8W 13.6V/8A Total Share 8A

2*DC552 Output

Max 108.8W 13.6V/8A Total Share 8A

Material

ABS+PC

Dimensions

34*30.6*22.5CM

Product Weight

15.8KG

PRODUCT SHOWCASE

Full Recharge Within

 1.5 Hours

Super Fast Recharge Technology enables you to fully charge the power station within 1.5 hours. That’s ideal when you need home backup power and a quick charge using your wall outlet a.

SOLAR PANEL FAST CHARGING

VDL HS1500 power supply supports two ports for charging solar panels.

DC5521 input port. 12-30V, max. 7A, max. 200W.

XT60 input port. 12-30V, max. 10A, max. 300W (including MC4 to XT60 connector)

When selecting the solar panel interface type, select either DC5521 or XT60 (XT60 is recommended to be preferred), the interface parameters need to be within the above parameters.

BMS – MAKING DEVICES SMARTER

Protected by a battery management system.

Trusted Mobile Power
Temperature Protection
Over-discharge protection
Overload protection
Charging protection
Short circuit protection
Overcurrent protection
Over-voltage protection
Power equalization

LCD SCREEN FOR MORE INTUITIVE USE

Keeps you informed of battery usage.

Remaining available time/output power/input power/battery power.

The screen has an automatic screen break power saving function. During use, if the screen automatically rests, press any button to restore the screen display.

EU 220V

UK 230V

AU 230V

YEARS OF EXPERIENCE

Over 15 years of experience In the industry. We focus on improving materials and technology and empowering users with meaningful innovation.

QUALITY ASSURANCE

100% quality guarantee,quick delivery time.

REPLY PROMPTLY

Promptly reply you within 24 hours.

BEST SERVICE

We treat clients as friend .Giving best service and sincere greetings.

Q1: What are the features of the VDL HS1500 Power Station?

A1:   It is a portable power station that can store 1228Kwh and can charge or power devices with different interfaces, such as cell phones, tablets, drones, refrigerators, rice cookers, induction cookers, hair dryers, coffee makers, televisions, respirators, etc. It can be recharged by AC, DC, etc, and then recycled use. It can be used in outdoor travel, outdoor photography, disaster prevention power outage, outdoor work, and other power shortage life scenarios to provide electricity. Make your life more colorful!

Q2: What are the restrictions on the appliances I use?

A2:  The total maximum AC output power of VDL HS1500 is 1500W (peak power is 2000W), so for all the appliances connect to AC ports the power consumption should be 1500W or less. Please check the power consumption column of the appliances you plan to use. Generally speaking, the power consumption is indicated on the appliance’s sticker.

Q3: How do I calculate the actual time available?

A3: During standby/operation of the product, its own power supply, screen, and/or inverter will have power consumption, so in general, when we measure the actual working time, it will be based on the theoretical value * 0.85.

That is: working time = 1228Wh * 0.85 / the working power of your device.

In addition, the remaining available time is displayed on the LCD screen of the product and can be used to estimate the remaining available time for most appliances. Since the power consumption of various appliances fluctuates during use, the remaining available time displayed on the LCD screen will also fluctuate and is for approximate reference only.
